SGM2576.pdf? 100mΩ (TYP) High-side N-Channel MOSFET
? Programmable Current Limit Range: 0.4A to 2.5A
1500mA ± 190mA@RILIM = 4.53kΩ
? Input Voltage Range: 2.5V to 5.5V
? Quiescent Current: 23μA (TYP)
? Shutdown Current: 0.1μA (TYP)
? Soft-Start Function
? Temperature Shutdown Protection
? Under-Voltage Lockout Protection for VIN
? No Reversed Leakage Current (Reverse Blocking)
? Automatic Output Discharge in Shutdown Mode (SGM2576 Only)
? 500kΩ Pull-Down Resistor at EN Pin
? Evaluated to IEC 60950-1, Ed 2, Am1, Annex CC,
Test Program 1 with CB Report
? Available in Green SOT-23-5 Package
? Adjustable Current Limiting up to 3.5A
? Built-In (Typically 80mΩ) N-MOSFET
? Reverse Current Flow Blocking (no body diode) i.e.
Output Can Be Forced Higher than Input (Off-State)
? Low Supply Current :
? 30μA Typical at Switch on State
? Less than 1μA Typical at Switch Off State
? Guaranteed 3A Continuous Load Current
? Wide Input Voltage Ranges : 2V to 5.5V
? Open-Drain Fault Flag Output
? Hot Plug-In Application (Soft-Start)
? 1.7V Typical Under-Voltage Lockout (UVLO)
? Thermal Shutdown Protection
? Smallest SOP-8 Package Minimizes Board Space
? RoHS Compliant and 100% Lead (Pb)-Free
